• Hiflow
  • HF1800-3 // Hiflow 1800mm bin lifter with patented EN840 comb hitch, 3P 415VAC power & boltdown lugs

Hiflow

Hiflow is a heavy-duty static bin lifter from Simpro, with high throughput capacity and a patented EN840 comb hitch to suit 240L, 660L and 1100L bins.
Stock Code:
0550230524
Stock Level
Lead time applies
Lead time applies

Add To Cart

Unavailable for Online Purchase

Hiflow is a heavy-duty static bin lifter from Simpro, with high throughput capacity and a patented EN840 comb hitch to suit 240L, 660L and 1100L bins. Hiflow was designed to seamlessly integrate with compactors, balers and other bulk waste-processing plant - replacing the unguarded, fixed-pivot bin lifts often found on such equipment.

With a lifting capacity of 600kg, Hiflow can empty all EN840-compliant wheelie bins up to 1100L. The standard model tips bins at 1800mm, but other heights can be specified with no change to the machine's compact two-square-meter floor footprint.

The Hiflow's patented comb-hitch mechanism has no actuators and just three moving parts, allowing it to handle the most demanding operations with little or no maintenance. The hitch distributes loads across the combing to minimise wear and tear on heavy HDPE bins.

By integrating Hiflow with their products, waste-equipment OEMs can reduce costs, improve compliance and deliver a better experience to end users. The Hiflow is backed by a two-year factory warranty.

- 1800mm tipping height
- 600kg capacity
- 4x boltdown lugs
- 3-phase mains power, 415VAC 50Hz <3A
- Heavy gauge perforated sheetmetal guarding
- Side-hinged doors with safety rated interlock system
- Two-year factory warranty

Features of the Simpro Hiflow Features of the Simpro Hiflow

Hiflow isometric views and dimensions

Hiflow Specifications
Model HF1800.3 HFxxxx.3 (Custom)
Tipping height 1800mm xxxx mm
Height 3460mm xxxx + 1660mm
Length 1440mm doors closed / 2355mm doors open
Width 1830mm
Weight ~510kg ~xxxx * 0.1 + 330kg
Capacity (max bin weight) 600kg
Bin compatibility 1x 1100L Wheelie Bin or 1x 660L Wheelie Bin or simultaneously 2x any of the following: 240L Wheelie Bin, 140L Wheelie Bin, 120L Wheelie Bin, 80L Wheelie Bin, 60L Wheelie Bin
Bin throw ~150mm
Electrical specifications 3-phase mains supply (380-415VAC 50-60hz, max draw 1.9 Amps), with 0.75kW AC electric motor, and 24VDC control circuit
User interface Raise/Lower buttons, key switch, master lockout switch (options: autocycle controls, E-stop button)
Ingress protection IP55 (options: IP66, IP69K)
Cradle travel speed 0.2m/s lifting / 0.3m/s lowering
Tipping cycle duration ~25s ~xxxx / 80 + 4s
Noise level at operator’s ear ⪅ 60dB(A)
Materials Hot-dip galvanised steel frame, bin hitch and tipping mechanism, with galvanised, powdercoated 1.6mm sheet steel guarding and safety covers
Door 2x heavy-duty side-hinge doors with solenoid-operated electrical safety interlocks
Mounting 4x bolt-down lugs
Applicable Standards and Certifications AS/NZS4024, AS/NZS3000, ISO 13849-1, IEC 62061, Conformité Européene (CE), EN 349 1993, EN 574 1996+A1:200, EN 953 1997, EN ISO 4413 2010, EN ISO 12100 2010, EN ISO13849-1 2006, EN ISO 13857 2008, EN 60204 2006+A1 2009, EN61000-6-2 2005, EN61000-6-4 2007, Machinery Directive 2006/42/EC, Electromagnetic Compatibility Directive 2004/108/EC



12 month Back to Base Warranty
